Albi

5713

Points

Discreet yet formidably effective, ALBI is the perfect floor recessed fixture to enhance the details of any interior. Compact and with no protruding parts, this small 4 LED spotlight is the mini version of the round adjustable recessed range. Its design allows 360° rotation within the recess, giving total freedom to adjust the luminous flux in the right direction, whatever the installation constraints. Its light module can be tilted (-10°/+30°), allowing you to finetune the lighting effect. Ideal for highlighting architectural elements, street furniture or creating atmosphere in squares and public spaces. Combining robustness and elegance thanks to its colorless anodized machined aluminum bezel, this recessed luminaire is also available in four-color process.

Get an IES file Data sheet EU Declaration of Conformity

Luminaire's body

Materials: Clear anodized machined aluminium

IP rating: IP68

IK rating: IK10 60 J

Integrated power supply: 24 V dc + PWM (class III)
230 V ac – non dimmable (class II)

Remote power supply via cable: 230 V ac – non dimmable (class II)

Remote power supply in distant box: 230 V ac -> 24 V dc + PWM
Control possible via: 0–10 V, DMX, DALI, potentiometers

Cable length: 100 cm

Features: 2-axis adjustable
Adjustable tray : – 10° à 30°
Transparent flat window

Optical unit

Color temperature: 2 200 K (A), 2 700 K (F), 3 000 K (E), 4 000 K (N), 6 000 K (W), Red (R), Amber (O), Green (V), Blue (L), Royal Blue (K)

Type of LED: Power LED

Number of LED: 4

Optics available: 10°, 20°, 36°, 52°, 77°, 120°, 130 x 25° (L1), 116 x 44° (L2), 40 x 10° (L4), 130 x 25° D50° (L5), 116 x 44° D36° (L6), 100 x 20° (L7). See details in the “Photometric
Specifications” document
